Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Installation and Service manual
Compass STD 22
Compass STD 22 Compact
4
Edition: Feb. 17, 2006
3646/110 --233.DOC010302
24VDC
18 -- 36 V DC
AC/DC converter
121--062
Option:
115--230VAC 50/60Hz
Compass
STD 22 Compact
110 --233
or
NMEA Position NMEA Speed Pulse Log Direction Pulse Log
2x Heading (course bus or NMEA) (CHn1 und CHn2)
Status
-- SEC -- System -- Available -- Quick Settling (Option)
Course bus
Additional Output
Box
146--103
NMEA 0183 su- perfast 50Hz
Step (6 steps/degree)
Option:

Quick Settling Operator unit
Option:
STD 22 Compact Gyro Compass
Inputs:
-- NMEA Speed -- NMEA Position -- P u l s e L o g -- Pulse Log Direction -- Status Quick Settling Operator Unit (Option)
Outputs:
STD 22 Compact Compass NG001
-- 2x Heading RMG course bus or NMEA
--1x status signal
-- 1x RMG Course bus for Output box
Output box
-- 1x NMEA 0183 superfast 50Hz -- 1x step (6 steps/degree)
Repeater compass

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
