Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
5
Edition: Feb. 17, 2006 3646/110 --233.DOC010302
24VDC
18 -- 36 V DC
AC/DC Converter
121--062
Option:
115--230V AC 50/60Hz
Compass
STD 22 Compact
110 --233
or
NMEA Position NMEA Speed Puls Log Direction Puls Log
2x Heading (course bus or NMEA) (CHn1 and CHn2)
Status
-- SEC -- System -- Available -- Quick Settling (Option)
Course bus
Distribution Unit compact
138--126

Operator Unit Quick Settling
Option:
Compass STD 22 with Distribution Unit compact
Heading repeater
18 -- 36 V DC
DISTRIBUTION UNIT COMPACT
Input:
-- Course bus
Outputs:
-- 12x outputs, separate adjustable:
either Course bus, NMEA 1 or NMEA 2
-- Statussignals:
System failure Compass failure Compass avaailable
-- 1x ROT or heading analogue -- 1x Course printer -- 3x Step
see manual No.:3646

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
