Installation and Service manual

Compass STD 22 Compact

Edition: Feb. 17, 2006

3646/110 --233.DOC010302

Continuous light

Course indication still inaccurate

For 4 hours after switching

on (Quick Settling: 1 hour)

Course indication can be

used*

* (not after initial installation)

flashing

“ quick Settling” function

is activated

Figure 31: Indications on the compass during the settling stage
