Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22 Compact
31
Edition: July 1, 2005 3646/110 --233.DOC010302
2.5 Creating cable connections and plug connections
2.5.1 Overview of plug connections and fuses on PCB‘s
(see also section 4 for more information about LED‘s, plugs, push buttons and jumper)
Connection PCB
NB05--356
Sensor PCB
110--233.X08
Power Supply PCB
110--233.102
Connection PCB
110--233.X13
Sensor PCB
110--233.X11
Power Supply PCB
110--233.X12
E10
Figure 14: Arrangement of PCB‘s i n the STD 22 Compact Compass (cover removed)
