Installation and Service manual
Compass STD 22 Compact
30
Edition: May 20, 2005
3646/110 --233.DOC010302
-- Using the thumbs, press down and engage two snap closures (Figure 13/1).
-- Turn the outer sphere through 90° and repeat the process with the two other snap
closures. The outer sphere is now fastened to the pendulum joint
-- Guide the cable around the outer sphere and attach the plugs to the small PCB
of the outer sphere, tighten the fastening screws
