Compass
Installation and Service manual
STD 22
Compass STD 22
Compass STD 22 Compact
I
Edition: Sept. 13, 2005
3646/110 --233.DOC010302
CONTENTS Page
Declaration of Conformity
Safety notes 1..............................................
1 General information 3......................................
1.1 CAN bus (CAN = Controller Area Network) 13...................
2 Preparing to install the STD 22 Compact Gyro Compass 15....
2.1 STD 22 Compact Compass – Scope of Supply 15................
2.2 General information concerning installation
of the STD 22 Compact Compass 16...........................
2.3 Creating cable connections 17.................................
2.3.1 General information concerning on-board wiring 17...............
2.3.1.1 General information about creating an earth connection 20........
2.4 Installing the compass and putting it into operation 21.............
2.4.1 Remove the transportation support with outer sphere,
supporting liquid and distilled water. 21..........................
2.4.1.1 Assembling the compass enclosure 22..........................
2.4.1.2 Installation of the gyrosphere 25................................
2.4.1.3 Filling with distilled water and supporting liquid 27................
2.4.1.4 Inserting the outer sphere in the compass enclosure 29...........
2.5 Creating cable connections and plug connections 31..............
2.5.1 Overview of plug connections and fuses on PCB‘s 31.............
2.5.1.1 Connecting the course receiver
in the STD 22 Compact Gyro Compass 33.......................
2.5.1.2 Connecting status and control signal outputs
in the STD 22 Compact Gyro Compass 35.......................
2.5.1.3 Connecting signal inputs for QS and SEC
in the STD 22 Compact Gyro compass 37.......................
2.5.1.4 Connecting the power supply cable 39..........................
2.5.1.5 Connecting the compass to earth 40............................
2.6 Installation and commissioning of optional features 41............
2.6.1 Installation and commissioning of
the Additional Output Box 143--103 41..........................
2.6.2 Installation and commissioning of the AC/DC Converter 121--062 43
2.6.3 Installation and commissioning
of the Operator Unit Quick Settling (QS) 130--606 46..............
2.6.3.1 Installing the Operator Unit Quick Settling 47....................
2.6.4 Switching on, settling and adjustment 49........................
2.6.4.1 Switching on the compass 49..................................
2.6.4.2 Checks on the compass 49....................................
2.6.4.3 Setting the STD 22 Compact Compass into operation 51..........
2.6.4.4 Setting the compass zero (reference course) 53.................
2.6.4.5 Reading the alignment error 55................................
2.6.4.6 Setting Channel 1 and Channel 2 56............................
2.6.4.7 Setting the information source for Speed Error Correction 59.......
2.6.4.8 Adjustment of essential operating modes 63.....................
2.6.4.9 Function check on externally connected course receivers 70.......
