Installation and Service manual
Compass STD 22
Compass STD 22 Compact
122
Edition: Feb. 17, 2006
3646/110 --233.DOC010302
5.1.1 Adjustments of parameters (in ascending order of function)
DIP--
switch
Step Display Function Push but-
ton B38
(left)
Push but-
ton B39
(right)
1 0 ALEr Alignment error setting decrease increase
1+2 0 Addr. Address setting CAN bus down-
wards
upwards
1to8 0 Fr.Cl Clearing Logs
1 E.L.Ci Error Log Clear, whole log will be cleared choose holdto0to
clear
2 Y.h .Cl Years, hours Clear choose holdto0to
clear
6 0 130.1 Fan, display and follow--up test -- -- -- -- -- -- -- -- -- -- -- -- -- --
5 0 -- F U -- Follow--up system manual operation,
Function check of RoT
turns cw turns ccw
7 0 FUoF Follow--up system turn off for service -- -- -- -- -- -- activate
2 0 nNEA NMEA telegram setting
1 nN1 NMEA telegram repetition 1Hz choose set
2 nN10 NMEA telegram repetition 10Hz choose set
3 HE.ro Heading telegram with ROT choose set
4 HE.---- Heading telegram without ROT choose set
5 SECY Activate SEC choose set
6 SECn Deactivate SEC choose set
7 oELY SEC with oil residual error choose set
8 oELn SEC withot oil residual error choose set
9 ddUY System with DU choose set
10 ddUn System without DU choose set
11 nMSy NMEA with SEC choose set
12 nMSn NMEA without SEC choose set
1+2+3 0 Chn1 Output channel 1, type of telegram
1 HSEr Select for heading serial choose set
2 nNEA Select for NMEA choose set
3 Chn2 Output channel 2, type of telegram
4 HSEr Select for heading serial choose set
5 nNEA Select for NMEA choose set
2+3 0 Pro ROT polarity setting choose set
1 ro Positive polarity for ROT choose set
2 ro -- Negative polarity for ROT choose set
3 0 A180 Settling phase bypass choose set
To Next Page
