Installation and Service manual
Compass STD 22
112
Edition: Feb. 17, 20063646/110--233.DOC010302
3.4.3.7 Function check on externally connected course receivers,
Function check of RoT
Unscrew and remove the cover of the compass enclosure.
Button B39
Button B38
DIP switch B37
Display
Button B39
Button B38 B37 DIP switch
Display
E10
Figure 65: DIP switch B37 and button B38/B39
Initial status:
12345678
OPEN
Display
DIP switch B37
ON
OFF
