Installation and Service manual
Compass STD 22
100
Edition: Feb. 17, 20063646/110--233.DOC010302
Continuous light
Course indication still inaccurate.
For 4 hours after switching on
(Quick Settling: 1 hour)
Course indication can be used!*
(not after initial installation)
flashing
”Quick Settling” function
is activated
Figure 60: Indications on the compass during the settling in stage
