Installation and Service manual
Compass STD 22
Compass STD 22 Compact
162
Edition: Feb. 17, 2006
3646/110 --233.DOC010302
Information concerning the error logbook (see also section 7.1):
Error -
code
Comment Error
group
E.L.01 Serial connection of sensor card to Power Supply PCB
faulty
PCbP
E.L.02 Inductive transmission faulty PCbP
E.L.03 System voltage (B5.5 ⇒ B5.8) on Power Supply PCB
faulty
PCbP
E.L.04 Encoder voltage faulty PCbP
E.L.05 System voltage (B5.1 ⇒ B5.4) on Power Supply PCB
faulty
PCbP
E.L.06 Encoder faulty PCbS
E.L.07 CAN dialogue from outer sphere PCB to sensor PCB
faulty
PCbS
E.L.08 Follow-up system faulty PCbS
E.L.09 CAN1 and CAN2 operating voltage faulty PCbC
E.L.10 Supporting liquid error PCbG
E.L.11 System voltage (B21.5 ⇒ B21.8) on outer sphere PCB
faulty
PCbG
E.L.12 Operating voltage 24V faulty PCbG
E.L.13 Operating voltage 15V faulty PCbG
E.L.14 Heating operating voltage (B21.1 ⇒ B21.4) faulty PCbG
E.L.15 Operating voltage 72V faulty PCbG
E.L.16 Operating voltage 78V faulty for 400 Hz PCbG
E.L.17 Gyro supply 55V
eff
faulty PCbG
E.L.18 Gyro current faulty PCbG
E.L.19 Pump voltage faulty PCbG
E.L.20 Pump current faulty PCbG
E.L.21 Temperature sensor faulty PCbG
E.L.22 Serial interface MC1 to MC2 faulty PCbG
E.L.23 CAN interface from sensor card to outer sphere PCB
faulty
PCbG
E.L.24 Heating system faulty PCbG
