Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
177
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
cont.
25
nSGL = NMEA--telegram (Strings of the GLL--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
24x
B38
13x
With the 1st operation o
f
the contact switch B38, the number o
f
ASCII--characters is displayed.
If the display shows “0000”, no telegram--output took place.
With every further operation of contact switch B38, 4 consecutive
ASCII--characters are displayed.
26 nSLL = NMEA--telegram (Strings of the SLL--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
25x
B38
Number of ASCII--char-
acters per telegram
0000 = no telegram
The number of operations depends
on the number of characters.
(1 display content = max. 4 ASCII--
characters)
See seq. no. 25
1x
