Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
179
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
29 nSbw = NMEA--telegram (String of the VBW--telegram)
12345678
OPEN
Switch B37 (DIP switch)
B39
28x
B38
1x
The number of operations depends
on the number of characters.
(1 display content =
max. 4 ASCII--characters)
See seq. no. 25
Number of ASCII--char
-
acters per telegram
0000 = no telegram
30
Development only!
Fb10 = Software component of speed error correction: Latitude
12345678
OPEN
Switch B37 (DIP switch)
B39
29x
B38
Latitude
