Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
189
Edition: Feb. 17, 2006 3646/110 --233.DOC010302
Following error groups can be displayed:
PCbP = Error on Power Supply PCB
PCbS = Error on sensor PCB
PCbC = Error on connection PCB
PCbG = Error on outer sphere PCB
Following error codes are possible (refering to their error group):
Error--
log
Comment Error
group
E.L.01 Serial connection of Sensor PCB to Power Supply PCB
faulty
PCbP
E.L.02 Inductive transmission faulty PCbP
E.L.03 System voltage (B5.5 ⇒ B5.8) on Power Supply PCB
faulty
PCbP
E.L.04 Encoder voltage faulty PCbP
E.L.05 System voltage (B5.1 ⇒ B5.4) on Power Supply PCB
faulty
PCbP
E.L.06 Encoder faulty PCbS
E.L.07 CAN dialogue from outer sphere PCB to sensor PCB
faulty
PCbS
E.L.08 Follow-up system faulty PCbS
E.L.09 CAN1 and CAN2 operating voltage faulty PCbC
E.L.10 Supporting liquid error PCbG
E.L.11 System voltage (B21.5 ⇒ B21.8) on sensor PCB faulty PCbG
E.L.12 Operating voltage 24V faulty PCbG
E.L.13 Operating voltage 15V faulty PCbG
E.L.14 Heating operating voltage (B21.1 ⇒ B21.4) faulty PCbG
E.L.15 Operating voltage 72V faulty PCbG
E.L.16 Operating voltage 78V faulty for 400 Hz PCbG
E.L.17 Gyro supply 55V
eff
faulty PCbG
E.L.18 Gyro current faulty PCbG
E.L.19 Pump voltage faulty PCbG
E.L.20 Pump current faulty PCbG
E.L.21 Temperature sensor faulty PCbG
E.L.22 Serial interface MC1 to MC2 faulty PCbG
E.L.23 CAN interface from outer sphere PCB to sensor PCB
faulty
PCbG
E.L.24 Heating system faulty PCbG
To delete the content of the error log book, see section 5.1.4 Nr. 14
