Compass
STD 22
Installation and Service manual
Compass STD 22 Compact
23
Edition: May 20, 2005 3646/110 --233.DOC010302
The compass enclosure must be installed in such a way that the following requirements
are met:
-- The 8 supports must all
stand on a flat, firm surface.
If necessary, the user should himself create an intermediate plate (marine quality
hardwood or metal) suited to the local conditions.
-- The compass enclosure must be screwed to the intermediate plate in a sea-resistant
fashion.
-- The intermediate plate must also be screwed to the ship’s body in a sea-resistant
fashion; this fastening is the responsibility of the user of the STD 22 Compact himself.
-- The compass enclosure must be mounted so that the digital display can be seen easily
after installation, the door of the compass enclosure can be opened and closed easily
and the cover of the compass enclosure can be detached.
-- The fastenings of the compass enclosure are indicated in the dimensional drawing
“Gyro Compass” (110 D 233 HP005) in the appendix to this manual.
The compass enclosure is fastened to the intermediate plate with 6 screws
S for woodscrews 11 x length depending on the thickness of the intermediate plate
S for metal screws M10 x length depending on the thickness of the intermediate plate.
The compass enclosure can also be mounted directly on a flat metal surface; in this case,
suitable stud bolts (M10) must be welded on; alternatively the compass housing can be
fastened on the underlying surface with threaded holes and screws M10--A4.
