Installation and Service manual
Compass STD 22 Compact
34
Edition: May 20, 2005
3646/110 --233.DOC010302
Course receivers should be connected with a screened cable having up to 6 poles (appr.
0.5mm
2
per conductor).
Output 1
(Channel 1)
Plug B2 Connection 3
Connection 4
Connection 5
Connection 1
Connection 2
Connection 6
Tx+
Tx--
Tx GND
24VDC
0V
Output 2
(Channel 2)
Plug B3 Connection 3
Connection 4
Connection 5
Connection 1
Connection 2
Connection 6
Tx+
Tx--
Tx GND
24VDC
0V
Output 3 Plug B4 Connection 3
Connection 4
Connection 5
Connection 1
Connection 2
Connection 6
Tx+
Tx--
Tx GND
24VDC
0V
