HandKey II Installation and Operation Manual
Page 10 Revision 2.0
Specifications
Table 1: Specifications
Size: 8.85 inches wide by 11.65 inches high by 8.55 inches deep (22.3 cm)
22.3 cm wide by 29.6 cm high by 21.7 cm deep
Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts
Weight: 6 lbs (2.7 kg)
Wiring: 2 twisted-pair, shielded, AWG 22 or larger (such as Belden 82732)
Temperature: -10C to +60C – non-operating/storage (14F to 140F)
0C to 45C – operating (32F to 113F)
Relative Humidity
Non-Condensing:
5% to 85% – non-operating/storage
20% to 80% – operating
Verification Time: 1 second or less
Memory Retention: 5 years using a standard internal lithium battery
Transaction Buffer: 5187 transactions
ID Number Length: 1 to 10 digits
Baud Rate: 300 to 28.8 K bps
Communications: RS-232, RS-485 4-wire (RS-422),
RS-485 2-wire, optional Ethernet, optional Modem
User Capacity: 512 users expandable to 32,512
Card Reader Input: Proximity, Wiegand, Magnetic Stripe, Bar Code
Card Reader Output: Wiegand, Magnetic Stripe, Bar Code
Duress Code: 1 leading digit, user definable
Door Controls: Lock output (open collector, sinks to ground, 100 mA max),
Request to Exit input, Door Switch input
Alarm Monitoring: Tamper, Door Forced, Duress
Event Monitoring: There is a variety of monitoring options including events such as:
Invalid ID, Time Zone Violation, ID Refused, Try Again,
Power Failure
Time Zones: 62 total – 2 fixed, 60 programmable
Auxiliary Outputs 3 user definable (open collector, sinks to ground, 100 mA max)
