HandKey II Installation and Operation Manual
Page 98 Revision 2.0
Aux Out Control
There are three outputs that can be set: 0, 1, 2. Output 0 can only be set when the Hand
Reader is in Lock and Auxiliary Output mode; Outputs 1 and 2 can be set regardless of
the mode the Hand Reader is in.
Outputs 0, 1, and 2 can be connected to a variety of peripheral devices such as audible
or silent alarms, door locks, or lighting systems. Verify Hand Reader/peripheral wiring
is correct and that the peripheral meets Hand Reader/system specifications before
changing the output settings. Table 9 describes the Auxiliary Output choices.
The following instructions demonstrate how to step through each of the Auxiliary
Output Control options.
1. When you enter the set Aux Out Control command the display appears as follows.
Table 9: Auxiliary Output Choices
Auxiliary Output Function
Aux Set by Time Zone Activated by a time zone.
Tamper Hand Reader opened, shaken, or removed.
TZ Violation User attempted entry during a restricted time period.
ID Refused User not verified after allowed number of tries.
Duress User entered the duress code digit.
Auxiliary Input 1 Auxiliary Input 1 switched to ground.
Auxiliary Input 2 Auxiliary Input 2 switched to ground.
Door Alarm Door forced open or held open beyond shunt time.
Try Again User rejected.
F1 Key F1 key pressed.
F2 Key F2 key pressed.
On Battery Backup AC power failure, Hand Reader switched to battery
power.
Unlock Door unlocked.
Auxiliary Keypad Auxiliary keypad is used.
