HandKey II Installation and Operation Manual
Page 124 Revision 2.0
Network Status
The following instructions demonstrate how to check the Hand Reader network status.
To check network status, the Hand Reader must be the Master Hand Reader in the
network.
1. When you enter the Network Status command the following appears on the
display.
2. Press to exit the command menu.
– or –
3. Press to skip to the Calibrate command.
4. Press to display Hand Reader Network Status. The status of the first 16 Hand
Readers in the Hand Reader network is displayed (addressed 0 to 15, from left to
right).
Each “O” and “.” represents a Hand Reader address in the network. An “O”
indicates that the Hand Reader corresponding to that address is communicating on the
network. A “.” indicates that the Hand Reader with that address is not communicating
on the network.
5. Press to display the status of the last 16 Hand Readers in the Hand Reader
network (addressed 16 to 31, from left to right).
6. Press to return to the Network Status command. The following appears on the
display.
NETWORK STATUS
*NO YES#
5
*
#
STAT: RDR 0-15
O O O O O O O O . . . . . . . .
NOTE
#
STAT: RDR 16-31
. . . . . . . . O O O O O O O O
#
