HandKey II Installation and Operation Manual
Revision 2.0 Page 23
Figure 3-2: Attaching the Hand Reader to the Wall Plate
4. Tighten all three lower mounting screws.
5. The Hand Reader is now ready for its wiring connections.
2 UPPER SCREWS
HOLE
SURFACE
CONDUIT
ENTRY
KEYHOLE
HOLES
3 LOWER
MOUNTING
SCREWS
REAR OF TERMINAL
