• 5. TECHICAL DATA "ELECTA"
Model 105 110 116
Application radiant panels
Nominal heating capacity (1) kW 6,57 10,00 16,19
COP (1) 4,15 4,38 4,04
Nominal heating capacity(1) EN 14511:2011 kW 6,48 9,87 16,00
COP (1) EN 14511:2011 4,34 4,58 4,20
Nominal heating capacity (2) kW 4,75 6,61 10,82
COP (2) 2,61 2,64 2,71
COP (2) EN 14511:2011 2,70 2,70 2,80
Nominal power cooling (3) kW 5,09 7,20 15,92
EER (3) 3,68 3,40 3,70
Nominal power cooling (3) EN 14511:2011 kW 5,18 7,30 16,11
EER (3) EN 14511:2011 4,02 3,61 3,91
Application fan
Nominal heating capacity (4) kW 6,26 9,84 15,40
COP (4) 3,03 3,36 3,30
Nominal heating capacity (4) EN 14511:2011 kW 6,18 9,75 15,20
COP (4) EN 14511:2011 3,12 3,44 3,40
Nominal power cooling (5) kW 3,75 5,45 12,40
EER (5) 2,72 2,74 2,81
Nominal power cooling (5) EN 14511:2011 kW 3,84 5,53 12,60
EER (5) EN 14511:2011 2,98 2,91 3,00
ESEER EN 14511:2011 4,00 3,35 3,90
Sound power (7) dB(A) 60 62 63
Sound pressure (6) dB(A) 35 37 38
Compressor Hermetic Scroll
Fan n° 1 1 2
Air flow rate
m
3
/h
3760 3600 7788
Heat exchanger nominal flow water side (5) l/min 10,75 15,62 35,53
Circulator available head pressure (5) kPa 85 55 90
Coolant filling R410A kg 1,05 1,72 2,99
Polyester oil charge kg See compressor plate
Electrical data
Absorbed power in winter operation (1) kW 1,59 2,28 4,01
Absorbed power in winter operation (2) kW 1,82 2,51 3,99
Absorbed power in winter operation (4) kW 2,07 2,93 4,67
Power consumption in cooling operation (3) kW 1,38 2,12 4,30
Power consumption in cooling operation (5) kW 1,38 1,99 4,41
Electrical power supply V-ph-Hz 230-1- 50
Auxiliary power supply V-ph-Hz 230-1- 50
Power consumption circulator kW 0,13 0,1 0,17
Nominal current (1) A 7,3 10,4 18,3
Nominal current (4) A 9,5 13,4 21,4
Nominal current (3) A 6,3 9,7 19,6
Nominal current (5) A 6,3 9,1 20,6
Maximum current A 11,2 17,5 25,3
Dimensions
Width (L) mm 898 850 1000
Height (H) mm 675 882 1418
Depth (P) mm 300 330 330
Water connections Ø 3/4 ” 1 ” 1-1/4 ”
Weight kg 52 74 118
Data referred to the following conditions:
1. In the following conditions: evaporator inlet air temperature 7°C B.S., 6°C B.U.; hot water temperature 35°C; differential temperature at the evaporator 5°C.
2. In the following conditions: evaporator inlet air temperature -7°C B.S., 6°C B.U.; hot water temperature 35°C to the same extent of the condition (1).
3. In the following conditions: condenser inlet air temperature 35°C; refrigerated water temperature 18°C; differential temperature at the evaporator 5°C.
4. In the following conditions: evaporator inlet air temperature 7°C B.S., 6°C B.U.; hot water temperature 45°C; differential temperature at the evaporator 5°C.
5. In the following conditions: condenser inlet air temperature 35°C; refrigerated water temperature 7°C; differential temperature at the evaporator 5°C.
6. Sound pressure level in dB(A) referring to measurement at 5 m from the unit, with directional factor equal to 2.
7. Sound power level in dB(A) on the basis of measurements taken in accordance with UNI EN-ISO 9614 and Eurovent 8/1.
(6((5(XURSHDQ6HDVRQDO((5(XURSHDQDYHUDJHVHDVRQDOHQHUJ\HI¿FLHQF\
64
