Menu parameters list “Set”:
Menu parameters list "Set" 1-2
Menù label Par Label Description U.m .
Range Default KCTR PW Address
min max
HP
100 tbEn
On: Activation of the heat pump On/Off time bands
Off: Deactivation of the heat pump On/Off time bands
- Off On Off 16465
101 MOdE
Operation mode: Cooling/Heating
0: Change through USER INTERFACE (and KCTR if
installed)
1: Change through external contact “Remote Cool/
Heat”, heating mode = open contact
2: Change through external contact “Remote Cool/
Heat”, heating mode = closed contact
- 0 2 2 S 16386
102 nigH Compressor maximum work frequency limit % Min 100 50 16388
SEnS
103 LAn
KCTR installation:
On:Installed
Off: Not installed.
- Off On S 16390
104 OFSt
Offset on the Room Temperature detected by KCTR
°C -5 5 0 S 16412
105 OFSH
Offset on the Room umiduty detected by KCTR
°C -10 10 0 S 16468
106 AMbt Room temperature detected by KCTR °C - -
Read
Value
8972
107 AMbH Room humidity detected by KCTR °C - -
Read
Value
8973
108 OUtA External environment temperature °C - -
Read
Value
8974
109 OUtU Temperature of outlet water from heat pump °C - -
Read
Value
X 8975
110 P3-4
&RQ¿JXULQJ WKH VLJQDO WR WHUPLQDOV 7HPS :DWHU
Supply System), on-SC:
0: STANDARD. Temperature signal from the sensor
on the return water. The connector "In WS" must be
connected to the TERMINAL BLOCK.
1: NTC_RADIANT. Is acquired water temperature to
the radiant system (sensor properly positioned by the
installer). The connector "In WS" must be disconnected
from TERMINAL BLOCK.
2: NTC_TANK. Is acquired temperature of inertial system
accumulation for the advanced management of an
additional generator (sensor properly positioned by the
installer). The connector "In WS" must be disconnected
from TERMINAL BLOCK (see Appendices "Advanced
Management additional generator").
3: Not used.
- 0 3 0 S 16389
111 in34
Temperature-signal input "Temp Water Supply
System "(terminals 3-4):
- If P3-4 = 0: return water temperature to the PdC
- If P3-4 = 1: water temperature at the outlet of the
radiant system
- If P3-4 = 2: the water temperature on the
accumulation, placed between the heat generators
and users
- If P3-4 = 3: not used
°C - -
Read
Value
8969
112 SAnt
State-temperature value storage tank, input "Sanitary
Water Tank Sensor" (terminals 5-6):
0.0 = contact open
0.1 = contact closed
°C - -
Read
Value
8976
113 dEUS
Input State Dew Point Sensor (terminals IN-COM):
On = closed contact. Moisture above the limit
Off = open contact. Humidity below the limit
---
Read
Value
8977
X=Parameter also available on KCTR
S = Password service (48)
69
