9.4 CAPACITIES AND PRESSURES AVAILABLE AT HEAT PUMP OUTLET
CAUTION
The pressure should not be less than 5 l/m (mod. 105), 6 l/m (mod. 110), 15 /m (mod. 116)
0
10
20
30
40
50
60
70
80
90
100
110
120
kPa
0 5 10 15 20
(L/min)
Speed 3
Speed 2
Speed 1
THAIY 105
0
10
20
30
40
50
60
70
80
010520
15 25 30 35 40
(L/min)
Speed 3
Speed 2
Speed 1
THAIY 110
0
20
40
60
80
100
120
140
(L/min)
01020304050
Speed 3
Speed 2
Speed 1
THAIY 116
PCB DISPLAY
SW3
ON
4
3
2
1
OFFON
4
3
2
1
OFFON
4
3
2
1
OFF
SW3
Speed 3
(Maximum)
Speed 2
(Medium)
Speed 1
(Minimum)
The circulator has three
speeds. The speed can be
selected from dip switches 1
and 2 of SW3 on the
PCB-TERMINAL BLOCK.
Speed 3 is factory-set
(Maximum).
kPa
kPa
89
