Ricoh A-P4 - Developer

4. Joint bracket [B].
5. Development roller [C] ( x2)
• Work carefully to avoid scratching or nicking the development roller.
Developer
1. Development unit (See ‘Development Unit’.)
2. Remove the development roller (See ‘Development Roller’.)
3. Tip out the old developer [A].
4. Turn drive gear [B] to ensure that no developer remains in the unit or on the development
roller.
• Dispose of the used developer in accordance with local regulations. Work carefully to avoid
scratching or nicking the development roller.
Development
91
3
