Photoconductor Unit (PCDU)
Overview of the PCDU
1 Toner Collection Coil 6 Transfer Entrance Guide
2 Toner Collection Plate 7 Charge Roller
3 Spur 8 Brush Roller
4 Pick off Pawl 9 Cleaning Blade
5 OPC Drum (φ60 mm)
6. Details
314
6
