6. Details
Machine Overview
Component Layout
1 Exit Roller 17 By-pass Paper End Sensor
2 Paper Exit Sensor 18 By-pass Paper Feed Roller
3 Hot Roller 19 By-pass Separation Roller
4 Entrance Sensor 20 Upper Relay Roller
5 Inverter Gate 21 Feed Roller
6 Inverter Roller 22 Separation Roller
7 Pressure Roller 23 Pick-up Roller
