Riso A2 - Master Disposal Box and Consumable Disposal

Replacing the Master Roll
110
Replacing and disposing consumables
3
Remove the depleted Master Core.
While reclining the Master Roll Lock Lever (1), remove
the core of the depleted Master Roll (2).
4
Install a new Master Roll.
Take a new master out from the package and place the
roll so that the mark on the Master Core comes to
the left (1).
While reclining the Master Roll Lock Lever, set the
master (2), and then remove the wrapper (3).
5
Insert the leading edge of the Master
Roll into its entrance under the
Master Guide Flap.
Insert the leading edge of the Master until it stops (1).
If the master is loose, turn the flange at the right inward
to rewind (2).
(1)
(2)
Dispose the depleted Master Core according to the
disposal procedure of your local community.
p.113 "Collection and Disposal of Depleted
Consumables"
NOTE
(3)
(2)
(1)
(2)
(1)
