Wrist Camera Instruction Manual
l If the accuracy is larger than +/- 4mm, an message will inform you that you should perform the calibration again.
l When you tap Accept, you will exit the wizard and the process is completed.
Once the calibration has been accepted, the Snapshot Position will appear in the Snapshot Positions tab with the name of
the Feature Point previously created. You can define other Snapshot positions, as long as you define new Feature Points.
To delete a Snapshot Position, tap the bin.
Tip
Make sure you save the Installation file (tap Load/Save from the Installation tab) in order to save the Snapshot
positions created.
©Robotiq inc. 2016-2018
36
