Wrist Camera Instruction Manual
Machine edge view
The user can access the machine view by tapping the Color view button in the upper right corner of the camera feed
window. The machine view makes no discrimination between colors; it rather highlights the contour of the selected object.
Fig. 5-7: Select Model step with Machine edge view enabled
Tip
The Machine edge view is a convenient tool that can be used to better understand the quality of the image and
the object contrast, and to improve adjustments made to the selection.
Tip
Tapping the cube button in the upper right corner of the camera feed window will bring up the Machine color
view.
