Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 181

Chapter 6 Configure the Redundant I/O System

See page 170 for a definition of parameters on the Module Info A tab.

8. Click the Module Info B tab.

The Module Info B tab appears. You set the parameters for Module B the

same way as Module A. See page 171

9. Click the Configuration tab.
