Rockwell Automation Publication 5032-UM001A-EN-P - April 2023 19
Chapter 2 Module Features
Carefully consider the implications of each keying option when selecting one.
For more detailed information on Electronic Keying, see Electronic Keying in Logix 5000
Control Systems Application Technique, publication LOGIX-AT001
.
Update Module Firmware The ArmorBlock 5000 8-channel IO-Link master module is manufactured with module
firmware installed. If updated module firmware revisions are available in the future, you can
update the firmware.
Updated firmware revisions are available for various reasons, for example, to correct an
anomaly that existed in previous module firmware revisions.
You access updated firmware files at the Rockwell Automation Product Compatibility and
Download Center (PCDC) at: rok.auto/pcdc
.
At the PCDC, you can use the module catalog number to check for firmware updates. If the
catalog number is not available, no updates exist then.
Input Events The ArmorBlock 5000 8-channel IO-Link master module can be configured with four input
event definitions.
To use Input Events, select the “Data with Events” or “Data with Events and Ethernet Status”
connection type in the IO-Link master Module Definition dialog.
To change the connection type, see General View
on page 45.
The following conditions can trigger events:
• An input state change
• A counting input done bit change
• A pattern of input state changes on multiple module inputs
When the module reports an input event to the controller, the module can trigger an event task
to execute in the controller. The event task lets you execute a section of logic immediately
when an event, or receipt of new data, occurs.
For more information on event tasks, see the Logix 5000 Controllers Tasks, Programs, and
Routines Programming Manual, publication 1756-PM005
.
Independent Point Trigger
An input state change or a counting input bit done change that triggers an event is known as
an independent point trigger.
To use this type of trigger, you must enable the Independent Point Trigger option in the event
definition. Set the EO.Eventxx.IndependentConditionTriggerEn tag to 1.
IMPORTANT Changing Electronic Keying parameters while the project is online
interrupts connections to the device and any devices that are
connected through the device. Connections from other controllers can
also be broken.
If an I/O connection to a device is interrupted, the result can be a loss
of data.
IMPORTANT Verify that you are using the correct firmware revisions for your modules
before commissioning your system.
