Appendix A
Troubleshoot Your IO-Link Master Module
This appendix describes how to identify and troubleshoot issues with your ArmorBlock 5000
8-channel IO-Link master module.
Module Status Indicator Table 15 describes the module status indicator for the ArmorBlock 5000 8-channel IO-Link
master module.
Network Status Indicator Table 16 describes the network status indicator for the ArmorBlock 5000 8-channel IO-Link
master module.
Table 15 - Module Status Indicator
Indicator State Description Recommended Action
Off The module is not powered. Apply power as necessary.
Steady green The module is operating in a normal condition. None
Flashing green The IP address is not set.
Set the IP address using one of the recommended methods. For
more information, see Configure the IO-Link Master Module
on
page 39.
Steady red The module experienced a nonrecoverable fault. Cycle power to the module. If the fault persists, replace the module.
Flashing red
One of the following conditions exists:
• A module firmware update is in progress.
• IP address switches do not match the configuration in use.
• The device has a recoverable fault. See the module diagnostics for more
information.
• The module has powered up and is in the Factory Default state. In this case,
all other indicators flash red and green.
Complete one of the following:
• Wait for the firmware update to finish.
• Cycle power to the module.
• Use module as necessary.
Flashing red/green
The module is performing a POST (power on self test), which completes within
30 seconds.
None
Table 16 - Network Status Indicator
Indicator State Description Recommended Action
Off The module is not configured or does not have an IP address. Configure the module or assign an IP address.
Steady green The module has an IP address and at least one established active connection. None
Flashing green The module has an IP address, but no active connections are established. Establish connections as required by the project.
Steady red There is a duplicate IP address condition or invalid configuration.
Troubleshoot the issue and remedy the cause.
For example, if a duplicate IP address condition exists, determine
which devices on the network use the same IP address and change
the IP address to unique values.
Flashing red One or more connections have timed out. Use module as necessary.
