98 Rockwell Automation Publication 5032-UM001A-EN-P - April 2023
Appendix C IO-Link Master Module and IO-Link Device Tag Definitions
IO-Link Master Module Tags This section describes the tags that are available for the ArmorBlock 5000 8-channel IO-Link
master module. The tables contained in this section list all tags that are available for the
module. Not all tags in the lists are used when the module is added to a project. Tag use varies
by module configuration.
The following types of tags are available:
• Configuration Tags for IO-Link Master Module
(as indicated by a ‘C’)
• Input Tags for IO-Link Master Module
(as indicated by an ‘I’)
• Output Tags for IO-Link Master Module
(as indicated by an ‘O’)
• Event Input Tags for IO-Link Master Module
(as indicated by an ‘EI’)
• Event Output Tags for IO-Link Master Module
(as indicated by an ‘EO’)
• Status Tags for IO-Link Master Module
(as indicated by an ‘S’)
Configuration Tags for IO-Link Master Module
Table 28 describes the available configuration tags (‘C’).
Table 28 - IO-Link Master Module Configuration Tags
Name Data Type Definition Valid Values
Counterxx.InputOffOnFilter SINT
The amount of time that a signal must be in the On state
before the input data indicates the On state.
The amount of time is indicated using an enumeration.
• 4 = 0 µs (default)
• 12 = 500 µs
• 13 = 1 ms
•14 = 2 ms
•15 = 5 ms
•16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.InputOnOffFilter SINT
The amount of time that a signal must be in the Off state
before the input data indicates the Off state.
The amount of time is indicated using an enumeration.
• 4 = 0 µs (default)
• 12 = 500 µs
• 13 = 1 ms
•14 = 2 ms
•15 = 5 ms
•16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Counterxx.RolloverAtPreset BOOL Set the counter to rollover to 0 at the preset value.
0 = Do not rollover (default)
1 = Rollover
IOLinkxx.Disable BOOL
Set to disable the channel temporarily.
When the channel is disabled, IO-Link communication on
the channel is deactivated.
0 = IO-Link communication is enabled (default)
1 = IO-Link communication is disabled
Ptxx.InputOffOnFilter SINT
The amount of time that a signal must be in the On state
before the input data indicates the On state.
The amount of time is indicated using an enumeration.
• 4 = 0 µs (default)
• 12 = 500 µs
• 13 = 1 ms
•14 = 2 ms
•15 = 5 ms
•16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Ptxx.InputOnOffFilter SINT
The amount of time that a signal must be in the Off state
before the input data indicates the Off state.
The amount of time is indicated using an enumeration.
• 4 = 0 µs (default)
• 12 = 500 µs
• 13 = 1 ms
•14 = 2 ms
•15 = 5 ms
•16 = 10 ms
• 17 = 20 ms
• 18 = 50 ms
Ptxx.ChatterTime INT
The amount of time within which the number of input
transitions are counted.
1…10000 ms
