Rockwell Automation Publication 5032-UM001A-EN-P - April 2023 27
Chapter 3 I/O Channel Features
Fault and Status Reporting The module sends fault and status data with channel data to the controller. The data is
returned through module tags that you can monitor in your Studio 5000 Logix Designer
application.
The ArmorBlock 5000 8-channel IO-Link master module provides the fault and data status in a
channel-centric format.
Table 5
lists the fault and status tags that are available for the IO-Link master module
channels in the Studio 5000 Logix Designer application.
We recommend that you monitor the tags in your program to make sure that the application is
operating as expected.
Table 6
lists the conditions that are shown in the channel diagnostics and diagnostic
assemblies.
For more information on fault reporting, see Troubleshoot Your IO-Link Master Module
on
page 79.
Table 5 - Fault and Status Tags for ArmorBlock 5000 8-channel IO-Link Master Module Channels
Data Type Tag Name Triggering Event That Sets the Tag
Fault
Ptxx.Fault The channel data quality is bad.
Counterxx.Fault The counter data quality is bad.
IOLinkxx.Fault The IO-Link data quality is bad.
Status
Ptxx.Data The point input status is 0 or 1.
Counterxx.Data The counter input status is 0 or 1.
IOLinkxx.Uncertain LA power for Class B device is faulted.
IMPORTANT Once the condition that causes the Fault or Uncertain tag to change to 1
is removed, the tag automatically resets to 0. The Studio 5000 Logix
Designer application controls the tags. You cannot change the status of
the tags.
Remember that in some system configurations, the tag is not reset
immediately after the condition is removed. The tag typically resets after
a short delay.
Table 6 - Diagnostic Conditions
Diagnostic Condition Description
SAPowerFault Indicates whether a fault exists on SA power
SAPowerFaultTimestamp The most recent time a fault on SA power occurred
LAPowerFault Indicates whether a fault exists on LA power
LAPowerFaultTimestamp The most recent time a fault on LA power occurred
SAPowerShortCircuit
Indicates whether a short circuit or overcurrent condition exists
on SA power
SAPowerShortCircuitTimestamp
The most recent time a short circuit or overcurrent condition on
SA power occurred
LAPowerShortCircuit
Indicates whether a short circuit or overcurrent condition exists
on LA power
LAPowerShortCircuitTimestamp
The most recent time a short circuit or overcurrent condition on
LA power occurred
NoLoad Indicates whether a No Load condition exists
NoLoadTimestamp The most recent time a No Load condition occurred
ShortCircuit Indicates whether a short circuit condition exists
ShortCircuitTimestamp The most recent time a No Load condition occurred
