40 Rockwell Automation Publication 5032-UM001A-EN-P - April 2023
Chapter 5 Configure the IO-Link Master Module
Use the BOOTP/DHCP Tool
The BOOTP/DHCP tool is a standalone server that you can use to set an IP address.
The BOOTP/DHCP tool sets an IP address and other TCP parameters.
You can use the BOOTP/DHCP tool to set the IP address when the device powers up in the out-
of-box state. The out-of-box state assumes that the network address switches on the module
are not set to a valid IP address (see Table 9
), and the module is DHCP enabled.
For instructions on how to use the BOOTP/DHCP tool to set the IP address, see the EtherNet/IP
Network Devices User Manual, publication ENET-UM006
.
Add the Module to a
Studio 5000 Logix Designer
Application Project
You must complete the following tasks before you can add the module:
Create a Studio 5000 Logix Designer application project.
Add a controller to the project.
For more information on how to add a controller to a Studio 5000 Logix Designer application
project, see the User Manual for the controller.
After you create a Studio 5000 Logix Designer application project and add a controller to the
project, you can use the following methods to add modules to the project.
Discover Modules
New Module
Table 9 - Values for Network Address Switches
Value Description
000
Exit Protected Mode.
Cycle power to the module and restore the switches to their previous values.
For more information, see Protected Mode for IO-Link Master Module on page 21.
001
Sets the module IP address to 192.168.1.1.
This value is valid but not recommended as this IP address is typically used by network switches.
002…253
Sets the module IP address to 192.168.1.xxx (where xxx is the value of the network address switches).
Subnet mask is set to 255.255.255.0 and the gateway address is set to 0.0.0.0.
The module does not have a host name that is assigned to it or uses any Domain Name Server (DNS).
254
Sets the module IP address to 192.168.1.254.
This value is valid but not recommended as this IP address is typically used by network switches.
888 Resets the module to factory default settings.
900
Enter Protected Mode.
Cycle power to the module and restore the switches to their previous values.
For more information, see Protected Mode for IO-Link Master Module
on page 21.
999
The module checks to see if DHCP is enabled.
If DHCP is enabled, the module requests for an IP address from a DHCP server. The DHCP server
also assigns other network address parameters.
If DHCP is not enabled, the module uses the IP address and other network address parameters
that are stored in nonvolatile memory.
