Roland XR-640 User Manual

1
Machine Highlights
Part Names and Functions
9
Front cover inside/print head periphery
Print-head carriage
The print head are inside
this.
Cutting carriage
The blade and the separating
knife are inside here.
Media clamps
These keep the media from
coming loose and prevent
fuzz on the cut edge of the
media from touching the
print head.
Grit rollers
These rollers feed out media toward
the front of the machine.
Platen
This is the path over which the me-
dia passes. A suction fan that keeps
the media from coming loose and
print heater that helps x the ink
are built in.
Blade protector
This protects the tip of the
blade during cutting.
Knife guide
The separating knife passes through
this when you perform media cuto.
Pinch rollers
These clamp the media when
the loading lever is pulled back
toward you.

Roland XR-640 Specifications

General

Ink Type	Eco-Solvent
Resolution	Up to 1440 dpi
Print Technology	Piezo inkjet
Max Print Width	64 inches
Ink Colors	CMYK
Media Thickness	Maximum 39 mil (1 mm) with liner
Connectivity	Ethernet
Print Speed	Up to 49 m²/hr (527 sqft/hr)
Media Width	64 inches
