Roland XR-640 - Media Take-Up System

1
Machine Highlights
Part Names and Functions
11
Media Take-up System
Take-up unit
This takes up media.
Dancer roller
This maintains uniform tension
for media.
MANUAL switch
You use this when you want to operate
the take-up unit manually.
AUTO switch
This makes the direction of rotation for take-
up during printing change automatically.
Take-up cable
This is connected to the
printer.
