Roland XR-640 User Manual

3
Maintenance
89
Replacing Consumable Parts
Replacing the Wiper
The wiper is a component that you use when cleaning the print heads. When the screen displays a message
like the one shown, it means the item needs to be replaced. Replace with new items.
Regarding the purchase of the wiper, contact your authorized Roland DG Corp. dealer.
CAUTION
Be sure to perform operations as specied by the following instructions,
and never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1. Display the [REPLACE WIPER] menu.

When the message shown in the gure appears, press
.

Remove any media from the platen.

Press .

Press several times until the screen shown on
the left appears.
Press
, and then .

Press , and then .

Press .
The print-head carriage moves to a location where wiper replacement
is possible, and then the screen shown in the gure appears.

Open the front cover.
TIME FOR
WIPER REPLACE
TIME FOR
WIPER REPLACE
MENU
SUB MENU
SUB MENU
MAINTENANCE
MAINTENANCE
REPLACE WIPER
OPEN FRONT
COVER
NOW PROCESSING. .

Roland XR-640 Specifications

General

Ink Type	Eco-Solvent
Resolution	Up to 1440 dpi
Print Technology	Piezo inkjet
Max Print Width	64 inches
Ink Colors	CMYK
Media Thickness	Maximum 39 mil (1 mm) with liner
Connectivity	Ethernet
Print Speed	Up to 49 m²/hr (527 sqft/hr)
Media Width	64 inches
