Reference
Modification-No.
- 0 -
Page
74
Date
1996 05 10
Install
914 F
19.2) Wiring diagram
See Ill. 52.
Legend to wiring diagram (Ill. 52)
Items 1-20 are included in the standard volume of supply of the engine
Items 21-25 are available as accessory
Items 30-51 can't be supplied
WARNING: The certification of items/components which are not included in the
standard volume of supply of engine has to be conducted by the
aircraft builder to the latest requirements such as FAR or JAR.
1 36 pole plug receptacle
2-3 plug connection for pressure sensor
4 plug connection for lamps
5 plug connection for servo motor
6 pressure sensor (static pressure, atmospheric pressure)
7 pressure sensor (airbox)
8 servo motor
9 2 electronic modules
10-11 plug connection for ignition switch
12 integrated generator
13-14 external regulator - rectifier with plug connections
15 electric starter
16-17 starter relay with plug connection
18-19 electric fuel pumps
20 3-way solenoid valve (float valve pressure)
21-23 external alternator with connections
24 electric rev-counter
25 capacitor
30-31 lamps
32 isolating switch for servo motor
33 2 ignition switches
34 master switch
35 starter switch
36 control lamp
37 amperemeter
38 battery relay
39 battery
40 bus bar
41 capacitor
42-51 circuit breaker
