Rotax 914 F Installation Manual

Reference
Modification-No.
- 0 -
Page
86
Date
1996 05 10
Install
914 F
19.4.10)Warning light
See Ill. 52.
➪ colour of lamp: red or colour as per effective regulations.
➪ voltage: 12 V(DC)
depending on input voltage of TCU.
➪ current: max. 0,5 A
➪ connections: + terminal: flexible cable 0,75 mm
2
white No. 10*
- terminal: flexible cable 0,75 mm
2
white No. 28*
* from the 36 pole plug receptacle of the TCU, plug 6,3 x 0,8 to DIN 46247
➪ length approx. 600 mm (24 in) from TCU
19.4.11)Caution light
See Ill. 52.
➪ Colour of lamp: orange or colour as per effective regulations.
➪ Voltage: 12 V(DC)
depending on input voltage of the TCU
➪ current: max. 0,5 A
➪ connections: + terminal: flexible cable 0,75 mm
2
white No. 11*
- terminal: flexible cable 0,75 mm
2
white No. 35*
* from the 36 pole plug receptacle of the TCU, plug 6,3 x 0,8 to DIN 46247
➪ length approx. 600 mm (24 in) from TCU
