Reference
Modification-No.
- 0 -
Page
79
Date
1996 05 10
Install
914 F
➪ Current:
■ ATTENTION: The graph current over engine speed has been determined
and is valid only at the following conditions.
ambient temperature: ...... 20 °C (68° F)
voltage: ............................ permanent 13,5 V
tolerance: ......................... max ± 5%
0
10
20
1000 2000 3000 4000 5000 6000
(A)
(1/min.)
Ill. 57
◆ NOTE: A charge-indicating lamp 3W/12V (Ill. 52, pos. s) may be fitted on
the instrument panel.
