1. Installation Method
1-7
[4] How to operate the fume control unit door
Press the bottom of the door with a finger and quickly release the finger,
and you will hear a click sound and the door will be unlocked [1] and
open [2].
To close the door, push it in until you hear a click sound.
Be careful not to pinch your hand.
If the door is not closed correctly, processing cannot be
performed properly.
[5] How to operate the paraffin oven door
Hold the handle and tilt it toward you to open the door [1].
To close the door, raise the handle toward the back.
Be careful not to pinch your hand.
If the door does not open, it may be stuck due to paraffin.
Forcibly opening the door may cause a breakdown.
[6] How to operate the Reagent bottle rack door
This is a double door.
Press the top of the door (center of the instrument), and you will hear a
click sound and the door will open slightly toward you [1].
The door is fixed with magnets, so pull it toward you to open [2].
To close the door, push it in until you hear a click sound. The door is
fixed with magnets.
Be careful not to pinch your hand.
Opening/closing the door with a strong force may damage
the door. Operate it gently.
