1. Installation Method
1-13
Connection port on
the container side
Connection port on
the instrument side
[6] How to set the paraffin container
How to set the paraffin container is explained.
Exercise caution against burns because the paraffin oven and paraffin may be hot.
Installing the paraffin container
1. Open the paraffin oven door.
2. Push the paraffin container all the way into the paraffin oven.
3. Close the paraffin oven door.
Removing the paraffin container
1. Open the paraffin oven door.
2. While applying slight force, gently and slowly pull out the paraffin container horizontally.
3. Close the paraffin oven door.
For the paraffin volume, refer to p. 2-3.
1. Confirm that input voltage has been set according to the installation environment.
2. Connect the power cord to the inlet on the instrument and power outlet on the facility side.
Use a power cable appropriate for the power-supply voltage.
Be sure to connect the power cord to a power outlet with grounding terminals.
3. Turn on the power switch on the right side face of the instrument monitor to start the instrument.
Set up the instrument as necessary.
