Sakura Histo-Tek VP1 User Manual

5. Basic Knowledge
1-19
1) Specification
General name
Vacuum Infiltration Processor
Brand name
Histo-Tek VP1
Model
VP1
Product code
1700
Manufacturing license number
20B2X00014000031
Instrument dimensions
Approx. 552 (W) x 604 (D) x 1,328 (H) mm (excluding projections) * Height to retort:
Approx. 1,033 mm
Instrument mass
Approx. 130 kg
Model
Floor model
Power supply voltage
100 VAC 50/60 Hz
115 VAC 50/60 Hz
220 to 240 VAC 50/60 Hz
Power consumption
1200 VA
Number of cassettes processed
Up to 300 cassettes (Tissue-Tek Uni-Cassette <Standard>)
1 station
Applicable reagents
• Formalin solution (including buffered formalin)
• Tissue-Tek U‐fix
• Methanol
• Ethanol
• Isoproyl alcohol
• Xylene
• Tissue-Tek Tissue-Clear
• Paraffin
• Water
Caution!
Do not use fixing solutions that contain mercury salt, acetic aid or
picric acid that corrodes metals.
Dispose of reagent properly according to the applicable regulation in
your country or region.
Do not use chloroform or toluene.
For any other chemical, contact the Sakura Finetek Technical Support
or local representative.
Usage of reagent
Processing solution volume; 3.2 to 3.5 L when processing 300 cassettes
Retort cleaning solution volume: 4.5 to 4.8 L
Fume treatment
Activated carbon filters, condenser
Mixing method
Pump-in and pump-out
Display
10.4 inch color LCD, touch screen
Operating
environment
Required facility
100 VAC 10%, 50/60 Hz: More than 15 A, with grounding terminal
115 VAC 10%, 50/60 Hz: More than 15 A, with grounding terminal
220~240 VAC 10%, 50/60 Hz: More than 10 A, with grounding terminal
Operating environment
Ambient temperature +10 to * 40C
Relative humidity 30 to 85% (non-condensing)
Storage environment
Ambient temperature -10 to +60ºC
Relative humidity 30 to 90% (non-condensing)
Applicable standards and
regulations
cETL Certification * Duplicate standards not
listed below)
UL61010-1-12
IVD Directive
* Duplicate standards not listed below
IEC61010-2-010:2014 Ed. 3
IEC61010-2-101:2015 Ed. 2
EN ISO14971:2012
EN61326-2-6:2013
EN62304:2006
EN62366:2008
Pharmaceutical and Medical Device Act
* Duplicate standards not listed below
ISO13485:2003
ISO14971:2007
JIS C 1010-1:2014
JIS C 1806-2-6:2012
Protection from Vibration and Drop
JIS Z 0200 : 1999 (Level 1)
JIS Z 0232 : 2004 (Standard of Truck
Transportation)
Protection against electric shock
Class I Pollution Degree 2
Installation category
II
Caution!
This product is specified for indoor use, so do not use it outdoors.
Note
The equipment specifications are subject to change without notice.
