Sakura Histo-Tek VP1 User Manual

3. Name of Each Part
1-16
[17] Retort lid
This lid is used to seal the retort. Open it to access the retort.
[18] Retort seal
[19] Retort
A station used for processing.
[20] Hook
This metal part locks the retort lid.
[21] Fume control unit (activated carbon filter)
This unit adsorbs the gases evaporating from solutions.
[22] Paraffin container
Molten paraffin used for tissue processing is put in this container.
[23] Reagent bottle
Solution used for tissue processing is put in this bottle. See below for the name of each Reagent bottle.
[24] Reagent bottle rack
Reagent bottles are stored in this rack.
[21]
[22]
[23]
[24]
[17]
[18]
[19]
[20] [4] [20]
<Front side of instrument>
<Back side of instrument>
Handle on the
top of the bottle
Bottle cap
Reagent bottle
Handle on the
front of the bottle
Label
Plug
Label
