Samsung DVM PLUS III - Page 145

II-105
I
NDOOR
U
NITS
8-8. Temperature and air flow distribution
1) Cooling air velocity distribution
Floor distance
Ceiling heigt
8 m
3 m
1 m
0 m
1 m 3 m 4 m
5 m
7 m
2 m
2 m
6
m
0.4m/s
0.2m/s
0.6m/s
◆ Discharge angle : 36°
Floor distance
Ceiling heigt
8 m
3 m
1 m
0 m
1 m 3 m 4 m
5 m
7 m
2 m
2 m
6
m
23
24
22
21
24
25
25
◆ Discharge angle : 36°
2) Cooling temperature distribution
Floor distance
Ceiling heigt
8 m
3 m
1 m
0 m
1 m 3 m 4 m
5 m
7 m
2 m
2 m
6
m
0.8m/s
1.0m/s
1.2m/s
0.6m/s
0.4m/s
0.2m/s
0.6m/s
0.4m/s
0.2m/s
◆ Discharge angle : 54°
3) Heating air velocity distribution
Floor distance
Ceiling heigt
8 m
3 m
1 m
0 m
1 m 3 m 4 m
5 m
7 m
2 m
2 m
6
m
27
29
31
29
27
25
23
21
◆ Discharge angle : 54°
4) Heating temperature distribution
AVXTFH071E✴ (Floor installation)
