Indoor Units
II-52
5
5
Slim duct
5-1. Features
Only 199mm thick, this slim design makes installation,
maintenance, and repair easy.
Slim design
After 1,000 hours of operation the filter clean indicator will alert you that
the filter should be cleaned. The filter can be easily removed from the
bottom, left, or right of the unit. (1,000 hours is the default set time,
which can be adjusted to 2,000 hours on the internal PCB.)
Easy filter cleaning
The air inlet can be set up on either the bottom or rear of the
unit, so there is more flexibility in installation.
Flexible installation
The smart pressure control system adjusts fan speed according to
external pressure, so the air conditioner always gives you consistent
cooling and heating airflow regardless of the surrounding environment.
Smart pressure control
Rear side air inlet Bottom side air inlet
Suction ductSuction duct
Tex
Diffuser
Diffuser
199mm
199mm
220mm
225mm
160 180 200 220210
230
Air volume
External static
pressure (mmAq)
H
H
M
M
L
L
Standard
Maximum
chapter2_Indoor units(052~107) 3/14/08 22:15 Page 52
