If possible, locate the power distribution unit in a place easy to connect with the watt-hour meter.
(switch box )
;
NN
NN
oo
oo
tt
tt
ee
ee
Power specifications
Comm. mode
Max. comm. line distance
Applicable watt-hour meters
220VAC, 50/60Hz
RS485
1000m
485 comm. type electronic watt-hour meters
(Omni System, Korea Micronix, HANSUK TECH,
LS Industrial Systems)
(2) Power, comm. specifications
3-phase 4-line 380V~415V
Indoor/Outdoor
comm. line
Watt-hour meter comm. line
Power line
Comm. line
220V
