Individual control system
1-3. Wired remote controller
2) MWR-WS00
(5) Installation
Operation Display
Power input
Indoor unit Tracking
Normal connection of indoor unit
Communication error
LCD is turned on for about 1second,
all segments are lit.
Temperature display indicates
Tracking is under way.
Displays the operation status of the connected
indoor unit.
Display A84 and E604 in turn.
After checking the communication line wiring between indoor unit and wired remote controller,
carry out power reset or tracking (Set +Cancel).
(A84 : Wired remote controller, E604 : Communication failure error between indoor unit and wired
remote controller)
Operation checking
