State display of indoor units
Blue : Operation
Gray : Stop
Red : Indoor unit error
Pink : Network error
White : Not registered indoor unit
R : Remote control restriction
C : Temperature limit
Indoor unit ON/OFF control
Selected indoor unit name display
Entire indoor unit selection/deselection
Optional display (Name/Temperature/Remote control display)
1
2
3
4
No. Description
Upper temperature limit setting
Lower temperature limit setting
1
2
5
3
1
54
2
1
2
Full display
Temperature limit setting
