Samsung DVM PLUS III - Centralized Control System

Unit : mm
Control Systems
V-46
2
2
Centralized control system
2-1. Interface module
1) MIM-B04A
(1) Features
(2) Dimensional drawing
• Communication device interfacing indoor/outdoor units with external control system
• Mainly used for upper system like centralized controllers/functions controllers/DMS
• 1 interface module for 1 outdoor unit
(DVM PLUS outdoor unit can have 2 interface units for over 16 indoor units.)
Â
F1 F2
F1 F2
50
80
